The H&H line of products also include specialty track hardware, including the 451 Really Useful Carrier, designed to enable attachment of scenery and other devices. Other products include pivoting devices, specialty scenery carriers, pipe clamps, and other track attachment components.

Part No: MiscTrack Category:

Available Options

ThumbnailSKUDescriptionPart Number ZincPart Number Black
439BS4 steel ball bearing wheels riveted to machined steel body. 3/8" forged eyebolt swivels in body and provides attachment point for scenery. Working Load Limit: 150#No. 139BS - for 110S track.No. 439BS - for 410S track.
440BS4 steel ball bearing wheels riveted to machined steel body. 1/2" milled tap bolt provided for scenery attachment. Working Load Limit: 150#No. 140BS - for 110S track.No. 440BS - for 410S track.
4494 urethane-tired sealed ball bearing wheels riveted to machined steel body for use with No. 410S or 410A track. Carrier provided with 2 Nylatron bearings to keep unit centered in the track assembly. 5/16" forged eyebolt swivels in body and provides attachment point for scenery. Working Load Limit: 200#No. 449
4504 urethane-tired sealed ball bearing wheels riveted to machined steel body for use with No. 410S or 410A track. Carrier provided with 2 Nylatron bearings to keep unit centered in the track assembly. 1/2" milled pinned tap bolt is provided for scenery attachment. Working Load Limit: 200#No. 450
450A8 urethane-tired sealed ball bearing wheels riveted to machined steel body for use with No. 410S or 410A track. Carrier provided with 2 Nylatron bearings to keep unit centered in the track assembly. 3/8" bolt provided with 2 hex nuts and lock washer for scenery attachment. Working Load Limit: 200#No. 450A
435BFormed 12 gauge steel brackets clamp to 1-1/4" or 1-1/2" standard pipe for suspending curtain tracks parallel to pipe. Working Load Limit: 150#No. 435 - Zinc plated.No. 435B - Black finish.
435RBFormed 12 gauge steel bracket U-bolts to 1-1/2" standard pipe for suspending curtain track perpendicular to pipe.No. 435R - Zinc plated.No. 435RB - Black finish.
435XB12 gauge steel strap with holes 1.9" on center. Used to extend pipe clamp when attaching to upper member of standard 1-1/2" pipe grid.No. 435X - Zinc plated.No. 435XB - Black finish.
448BFormed 1/4" steel bracket with offset tab for suspending curtain track from 1/2" rod. Working Load Limit: 150 pounds.No. 448 - Zinc plated.No. 448B - Black finish.
442-22 pound smooth cast iron weight with eye.No. 442-2
447A1-9/16" X .120" steel tubing, 24" long, for use as internal sleeve for 1-1/2" Sch. 40 pipe batten. With 4 drilled holes and (4) 3/8-16 x 2-1/2" bolts and Nylock hex nuts.No. 447No. 447A - Same as 447 Splice except no attachment holes. (4) 3/8-16 x 2-1/2" bolts and Nylock hex nuts provided.
6436" Nylatron GS sheave with precision ball bearings in specially designed housing with heavy-duty sand bag. For maintaining proper operating line tension on flying curtains. Supplied without sand. Grooved for up to 1/2" operating line.No. 643
