MOTORIZED STACKING VARIABLE ACOUSTIC BANNER

Our acouStac Banner Systems includes Banner Machines, Motor Starters/MCPs, and Controller.

Our unique design allows the acoustic fabric panel to retract and neatly compress to store below the machine frame. At full deployment, a bottom weight introduces tension to the fabric surface for optimal acoustic control.

All our banners are built with acouStaCorp 100% Wool Serge (DFR, 550gsm) for a high density weave without nap or synthetic sheen. Wool is recommended by acousticians as an effective sound absorber across a wide range of frequencies. Click here to find out more.

Our banners are independent lab certified for absorption coefficients under ASTM-C423- test reports available upon request.

The 2016 life cycle test benchmark was made at 15,000 continuous cycles, representing a service life of 20 years with twice daily operation. Testing was concluded at 38,000 continuous cycles without failure.

Our heavy-duty aluminum machine frame has removable polyvinyl infill panels and a standard mill finish aluminum- custom enclosures and closure panels available.

 The integral mounting system is built into the frame, making it easy for ceiling or wall installation- other custom mounting options are also available.

 Motor size ranges from ¼ HP to ¾ HP depending on the size of the fabric panels, and all motor options are extremely quiet for distraction-free operation.

 Our motors are equipped with a 3-Phase, 208VAC, 60 Hz external gear motor with a minimum service factor of 1.25.

 Standard travel speed is nominal 24 fpm. Optional fixed speeds from 34 fpm to 100 fpm and variable speeds from 0-34 fpm up to 1-100 fpm are available.

Our design uses stainless steel lifting bands that are designed for a safety factor of not less than 8:1.

Yo-Yo style drums spool the lifting bands for reliable fabric tracking and stacking.

acouStac Product Options

The acoustic chamber consists of individual horizontal fabric segments secured into our rail & stacker system. 3” or 6” stackers maintain a fixed depth over the full height and width of the banner panel. Segments can be easily removed for cleaning or replacement.

Acoustic Chamber Dimensions:

3W11  –  3” panel depth with 11” tall segments
6W11  –  6” panel depth with 11” tall segments

3W15  –  3” panel depth with 14” tall segments
6W15  –  6” panel depth with 14” tall segments

Our standard fabric panel is 20’ wide x 20’ tall. Custom fabric panel sizes available.

Click here for color options (custom colors available at no additional charge).

acouStac Control Options

All banners are compatible with the acouStaCorp Symphony Automation Controller or any Deck Boss® control options from Texas Scenic, as well as can be integrated into third party controllers- click here for controls options, or contact us about third party integration.

Warranty

Warranted to be free from defects of material and workmanship for three (3) years. All variable acoustic banners are manufactured in Bronx, NY, and shipped fully assembled and tested.

For technical, design and custom product support click here to request a Design & Site Coordination Guide.
